MOTICAM PROS5 LITE

SKU
1100600101101
$1,028.70

Moticam Pro S5 Lite with 5MP resolution delivers best conditions to document large samples from all biological/medical fields, at the same time showing high low-light sensitivity. The global shutter readout helps to accelerate data transfer moving/fast phenomena from biology and industrial production.

Model Moticam Pro S5 Lite
Sensor Type sCMOS
Sensor Size 2/3"
Imaging Area 11.1mm (Diagonal)
Capture Resolution Info 5MP
Live display mode through USB 2448x2048, 1224x1024 pixels
Pixel size 3.45x3.45μm
Scan mode Progressive
Shutter mode Global shutter
Data transfer USB 3.1
Max. frames per second (fps) 2448x2048 @ 37.5fps 1224x1024 @ 88.4fps (*)
Exposure time 14 μsec to 2 sec
Operating temperature From -10 to +60 Degrees Celsius non condensing
Max. signal to noise ratio 0.1mV @1/30 sec
Sensitivity 1146mV(G) @ 1/30 sec
Support device TWAIN, SDK and DirectShow Driver
Supported OS Windows 7/8/10, MAC OSX, Linux or higher
Minimum computer requirements 2GHz dualcore - RAM memory 2GB - Video memory min. 512 MB
Lens mount C-Mount
Software Motic Images Plus 3.0 for Windows, OSX and Linux
Functions Still image and video capture, live and still image measurement, image adjustments, white balance, automatic & manual exposure, individual objective calibration system.
Power supply 5V (From USB Port)
Package includes CS ring adaptor, USB 3.1 cable, Motic 4-dot calibration slide, Motic Images Plus 3.0 for Windows/OSX/Linux
Other features (*) Frames per second under optimal lighting conditions and in compliance with computer technical requirements.
More Information
MSRP 1,143.00
STEM Approved No
Connection Type USB
Power None
